OV4689 MIPI built-in lub koob yees duab module 6G puv iav fisheye 1080P30 ncej 2K lub koob yees duab

Lus piav qhia luv luv:

Product Detail

Khoom cim npe

Khoom Parameter

Module Specification:	YXF-HDF4689-A46-210
Module Loj:	14mm * 14mm * 46mm
Module Hom:	YXF
Saib lub kaum sab xis:	210 °
Focal Length (EFL):	/
Aperture (F / NO):	1.8
Distortion:	<24%
Hom Chip:	ua 4689
Chip Hom:	OmniVision
Hom interface:	MIPI
Active Array Loj:	4000,000 pixels 2688 * 1520
Lens Loj:	1/3 nti
Core voltage (DVD)	1-1.3 V
Analog Circuit Court voltage (AVDD)	2.6 ~ 3.0V
Interface Circuit Court voltage (DOVDD) (I / O)	1.7V rau 3.6V
Module PDF	Thov hu rau peb.
Chip PDF	Thov hu rau peb.

ODM / OEM CUSTOMIZED CAMERA MODULE yog muaj!

Peb muab cov khoom lag luam zoo thiab sib xws CMOS Lub Koob Yees Duab Module rau kev thov sib txawv thiab kev xav tau los ntawm cov neeg siv khoom.Peb cov khoom lag luam zoo tshaj plaws hauv ntiaj teb thiab kev tsim khoom yog raws li cov chaw niaj hnub thiab kev tswj xyuas zoo rau CMOS Lub Koob Yees Duab Module cov khoom.

Qhov no 10-ntsis RAW RGB tso zis hom 2k kev ua si nawv lub koob yees duab module MIPI CMOS Lub Koob Yees Duab module OV4689, nws muaj qhov loj me me thiab tau siv dav hauv xov tooj ntawm tes, ntsiav tshuaj, Laptop, Lub Cev Hnav Lub Koob Yees Duab, Drone, Digital Tseem Yees Duab, MP4, Mini DVR, Lub Koob Yees Duab Rov Qab, DV, PDA / Handheld, Khoom Ua Si, Lub Koob Yees Duab PC, Lub Koob Yees Duab Kev Ruaj Ntseg, Lub Koob Yees Duab Tsheb, thiab lwm yam.
